PLANET IGS-5225-4P2S network switch Managed L2+ Gigabit Ethernet (10/1

Advanced Manageable PoE Solution for Hardened Environment PLANET IGS-5225-4P2S L2+ Industrial Managed PoE+ Switch. featuring 4 10/100/1000BASE-T 802.3at PoE+ ports with each port powering up to 36 watts. and 2 100/1000X fiber ports in an IP40 rugged but compact-sized case. can be installed in any difficult environment without space limitation. It provides user-friendly yet advanced IPv6/IPv4 management interfaces. abundant L2/L4 switching functions. Layer 3 static routing capability. and advanced ITU-G.8032 ERPS Ring technology to improve the rapid self-recovery capability and PLANET intelligent PoE functions for controlling the PoE outdoor IP surveillance and wireless network applications. It is able to operate reliably. stably and quietly in the temperature range from -40 to 75 degrees C. Redundant Ring. Fast Recovery for Critical Network Applications The IGS-5225-4P2S supports redundant ring technology and features strong. rapid self-recovery capability to prevent interruptions and external intrusions. It incorporates advanced ITU-T G.8032 ERPS (Ethernet Ring Protection Switching) technology. Spanning Tree Protocol (802.1s MSTP). and redundant power input system into customer’s industrial automation network to enhance system reliability and uptime in harsh factory environments. In a simple Ring network. the recovery time of data link can be as fast as 10ms. Cybersecurity Network Solution to Minimize Security Risks The cybersecurity feature that virtually needs no effort and cost to have includes the protection of the switch management and the enhanced security of the mission-critical network. Both SSH and SSL protocols are utilized to provide strong protection against advanced threats. The network administrator can now construct highly-secure corporate networks with considerably less time and effort than before. Convenient and Smart ONVIF Devices with Detection Feature PLANET has newly developed an awesome feature -- ONVIF Support -- which is specifically designed for co-operating with video IP surveillances. From the IGS-5225-4P2S’ GUI. you just need one click to search and show all of the ONVIF devices via network application. In addition. you can upload floor images to the switch and can remotely monitor or inspect an assembly line. Moreover. you can get real-time surveillance information and online/offline status; the PoE reboot can be controlled from the GUI. Built-in Unique PoE Functions for Powered Devices Management As it is the managed PoE switch for surveillance. wireless and VoIP networks. the IGS-5225-4P2S features the following special PoE management functions: - PD alive check - Scheduled power recycling - PoE schedule - PoE usage monitoring Intelligent Alive Check for Powered Device The IGS-5225-4P2S PoE Switch can be configured to monitor connected PD’s status in real time via ping action. Once the PD stops working and responding. the IGS-5225-4P2S will recycle the PoE port power and bring the PD back to work. It also greatly enhances the reliability in that the PoE port will reset the PD power. thus reducing administrator’s management burden. PoE Schedule for Energy Saving Under the trend of energy saving worldwide and contributing to environmental protection on the Earth. the IGS-5225-4P2S can effectively control the power supply besides its capability of giving high watts power. The built-in “PoE schedule” function helps you to enable or disable PoE power feeding for each PoE port during specified time intervals and it is a powerful function to help SMBs or enterprises save power and money. Scheduled Power Recycling The IGS-5225-4P2S allows each of the connected PoE IP cameras or PoE wireless access points to reboot at a specific time each week. Therefore. it will reduce the chance of IP camera or AP crash resulting from buffer overflow. SMTP/SNMP Trap Event Alert The IGS-5225-4P2S provides event alert function to help to diagnose the abnormal device owing to whether or not there is a break of the network connection. or the rebooting response. Effective Alarm Alert for Better Protection The IGS-5225-4P2S supports a Fault Alarm feature which can alert the users when there is something wrong with the switches. With this ideal feature. the users would not have to waste time finding where the problem is. It will help to save time and human resource. Layer 3 IPv4 and IPv6 Software VLAN Routing for Secure and Flexible Management To help customers stay on top of their businesses. the IGS-5225-4P2S not only provides ultra high transmission performance and excellent Layer 2 technologies. but also IPv4/IPv6 software VLAN routing feature which allows to cross over different VLANs and different IP addresses for the purpose of having a highly-secure. flexible management and simpler networking application. Robust Layer 2 Features The IGS-5225-4P2S can be programmed for advanced switch management functions such as dynamic port link aggregation. Q-in-Q VLAN. private VLAN. Rapid Spanning Tre
