DrayTek VSP2540XS-K network switch Managed L2+/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black

48 x RJ-45 Gigabit Ethernet Ports with PoE+. 6 x SFP+ 10GbE Ports for Uplink / Fibre. PoE (Power-over-Ethernet) for IP phones, wireless access points, IP Cameras etc. 400-watt Power-over-Ethernet budget. 802.1q VLANs with Dynamic MAC-based, Voice & Surveillance VLAN. VLAN Routing & Static Route with DHCP server / relay. Virtual Router Redundancy Protocol. QoS for Application traffic prioritisation. 802.1x RADIUS / TACACS+ Port Authentication with Accounting. Voice VLAN for QoS (OUI Mode). Access Control List (ACL). Port Mirroring & Link Aggregation. IGMP Snooping & Querying. IPv4 and IPv6 Support with IP Conflict Prevention. Hardware Monitor with smart fan control. Centrally managed or standalone operation. Console Port. 10GbE Gigabit Switch with 48 Gigabit PoE+ Ports & 6 10GbE SFP+ Uplink Ports. VigorSwitch P2540xs is a 54 port PoE+ Gigabit L2+ Managed switch with a plethora of management options and enterprise-level features to improve network stability and security for businesses.. It has 48 PoE+ (Power over Ethernet) RJ-45 LAN ports and 6 10-Gigabit Ethernet SFP+ ports for high bandwidth uplinks to Servers, Network Attached Storage and Switches.. Designed for centralised management, the VigorSwitch P2540xs can be provisioned and monitored through both the VigorACS management platform and/or, a DrayTek Vigor router’s Central Switch Management. Easily provision the VLAN configuration through the router and clone switch configurations. Drastically reduce the setup time required for a complex network, with VLANs spanning multiple switches.. High Speed 10 Gigabit SFP+ Uplinks. 6 SFP+ ports allow your network to utilise 10Gbps ports to link Switches, Servers and Networked Storage with more bandwidth. This helps you reduce the risk of bottlenecks occurring in your network.. Benefits: Easily increase network throughput and meet demanding bandwidth requirements.. Manage Centrally or Stand-Alone. Configure and monitor the switch through the VigorACS cloud management platform, DrayTek's Central Switch Management for Vigor routers, or directly via the device's Web Interface.. Benefits: Saves time and money. Easily provision, monitor and manage remote sites without on-site IT or dedicated staff.. Great Security Features. Protect your network against unauthorised access and network problems with 802.1X port authentication, DHCP Snooping, IP Source Guard and Access Control Lists. Check the features sections for more information.. Benefits: Secure & control access to your network.. Advanced Layer 2+ Routing Features. Expand your network with support for Layer 3 features such as Static Routes and VLAN Routing, to connect separate networks through the VigorSwitch.. Benefits: Provides a fast and secure bridge between networks.. 400W PoE Power Budget. Provides power through Ethernet to each of the 48 PoE / PoE+ enabled Gigabit LAN ports. PoE scheduling, priority & monitoring features ensure your PoE devices are powered and working.. Benefits: Power a large number of IP cameras, IP phones, wireless APs and other PoE devices.. IP Camera Management. Manage IP Cameras easily with detection and management of ONVIF cameras. Use PoE Device Check, auto-generated IP Camera topology and Camera Snapshots to detect & troubleshoot problems.. Benefits: Easily configure, deploy & manage connected IP Cameras.. Management features. Traffic classification. Yes. ARP inspection. Yes. Configuring Location Settings (CLI). Yes. Web-based management. Yes. Cloud-managed. Yes. Quality of Service (QoS) support. Yes. Switch layer. L2+/L3. Switch type. Managed. Ports & interfaces. Console port. RJ-45. Fiber optic connector. LC. Fiber ports quantity. 6. Installed SFP+ modules quantity. 6. Basic switching RJ-45 Ethernet ports type. Gigabit Ethernet (10/100/1000). Basic switching RJ-45 Ethernet ports quantity. 48. Network. Number of VLANs. 256. VLAN support. Yes. Link aggregation. Yes. Flow control support. Yes. Auto-negotiation. Yes. Rate limiting. Yes. Broadcast storm control. Yes. Spanning tree protocol. Yes. Full duplex. Yes. Port mirroring. Yes. Copper ethernet cabling technology. 10BASE-T, 100BASE-T, 1000BASE-T. 10G support. Yes. Networking standards. IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x. Optical fiber. Fiber ethernet cabling technology. 10GBASE-LR, 10GBASE-LRM, 1000BASE-LX. Data transmission. Jumbo frames. 12. Jumbo frames support. Yes. Static route. Yes. Number of queues. 8. Forwarding rate. 160.7 Mpps. Switching capacity. 216 Gbit/s. MAC address table. 32 entries. Security. Loop protection. Yes. Security algorithms. HTTPS, SNMPv2, SNMPv3, SSH, SSH-1.5, SSH-2. Authentication type. AAA, RADIUS, TACACS+. MAC address filtering. Yes. Password protection. Yes. SSH/SSL support. Yes. IP-MAC-Port binding. Yes. Static port security. Yes. IGMP snooping. Yes. Access Control List (ACL)
